| Characteristic | Parameter |
|---|---|
| Optical | |
| Focal Length | 30.5mm～305mm |
| F/# | 4.0 |
| Wavelength Range | 3.5~5μm |
| Average Transmittance | ≥86% |
| Detector Type | 640×512, 15μm |
| Field of View | 17.45°×14.04° (30.5mm) 1.93°×1.55° (305mm) |
| Mechanical | |
| Focus Type | Motorized |
| Focus Range | 10m~∞ |
| Overall Dimensions | 111×103.8×96.1mm |
| Back Working Distance | 14.096mm |
| Weight | 1050g |
| Environment | |
| Operating Temperature | -40℃~+60℃ |
| Storage Temperature | -50℃~+70℃ |
1、10x High Zoom Range: 30.5mm~305mm optical zoom balances wide-angle vision and long-distance detail capture, adapting to diverse monitoring scenarios.
2、Constant Aperture: F/4.0 consistent aperture ensures uniform light intake across all focal lengths, guaranteeing stable image brightness and clarity.
3、High Transmittance: Optimized for 3.5~5μm MWIR band with ≥86% average transmittance, effectively improving image signal-to-noise ratio.
4、Motorized Focus Control: Supports automated focus adjustment (10m~∞), compatible with intelligent imaging system integration.
5、Wide-Temperature Adaptability: Operates reliably in -40℃~+60℃, suitable for harsh industrial and outdoor environments.
6、Compact & Lightweight: Compact dimensions (111×103.8×96.1mm) and 1050g weight, facilitating easy device integration and installation.
